SUBMERSIBLE SEWAGE PUMPS
Low Speed Heavy Duty Sewage And Effluent Submersible Pumps
Technical Specification |
|
| Capacity: | Up To 2000 M3/hr |
| Head: | Up To 70 Mtr. |
| Temperature | 45 C° |
| HP: | 2 To 200 |
| Speed: | 960 To 1440 RPM |
| Dilivery Size: | 50 mm To 200 mm |
| Solid Size: | 125 mm |
| Connection: | Dol, Star Delta, ATS |
| Voltage & Phase: | 415V, 3 Phase |
| Insulation / Protection: | ' F ' Class / 'H' Class - IP 68 |
| Cable: | PVC Insulated Double Seated Copper Conductor Flexible Cable |
| Mechanical Seal: | Bi-Directional Twin Mechanical Seal with various Face Combination Looking To Tha Application. |
| M.O.C.: | C.I., C.S., S.S. |
| Optional Parts: | Impeller, Casing, Wear Plate with Variouse M.O.C. Bronze, CF8, CF8M, CD4MCU etc..... |
| Application: | Muddy Water Transfer, Effluent Transfer, ETP, STP, Wast Treatment Plant. Hotel Hospital, Railway, Dairy, Power Plant, Chemical Industries, Suger, Steel, Cement, Food Beverages Etc.. |
High Speed Light Duty Sewage And Effluent Submersible Pumps
Technical Specification |
|
| Capacity: | Up To 132 M3/hr |
| Head: | Up To 50 Mtr. |
| Temperature | 45 C° |
| HP: | 0.5 To 10 (1 to 2 HP In Single Phase) |
| Speed: | Up To 2880 RPM |
| Dilivery Size: | 25 mm To 100 mm |
| Solid Size: | 50 mm |
| Connection: | DOL |
| Voltage & Phase: | 415V, 3 Phase / 215 V, 1 Phase Up To 2 HP |
| Insulation / Protection: | ' F ' Class / 'H' Class - IP 68 |
| Cable: | PVC Insulated Double Seated Copper Conductor Flexible Cable |
| Mechanical Seal: | Bi-Directional Twin Mechanical Seal with various Face Combination Looking To Tha Application. |
| M.O.C.: | C.I., C.S., S.S. |
| Optional Parts: | Impeller, Casing, Wear Plate with Variouse M.O.C. Bronze, CF8, CF8M, CD4MCU etc..... |
| Application: | Muddy Water Transfer, Swiming Pool, Dewatering Of Ponds, Basement of Huge Building, Power, Power Plant Effluent Transfer, ETP, STP, Wast Water Treatment Plants, Hotel Hospital, Railway, Dairy, Power Plant, Chemical Industries, Suger, Steel, Cement, Food Beverages Etc.. |
